ASA Fiberglass Filament - 1.75mm±0.03mm (1kg)

€32,99
Frais d'expédition calculés à l'étape de paiement.
Color: Black
Color: Black





ASA-GF

Eryone ASA-GF is an easy-to-print 3D printing material characterized by high
strength, high rigidity, weather resistance, anti-yellowing, aging resistance, and
corrosion resistance. It is designed for easy shaping, with a low tendency to crack or
warp, and supports open printing environments. The printed parts are robust and
feature a matte, frosted surface texture. This material is ideal for applications requiring
specific strength or weather resistance in end-use products, such as automotive interior
components, garden furniture, and outdoor leisure structures. It contains 10% fiberglass.

Part I:Suggests Printing Parameters

Parameter  Set up
Nozzle temperature 260℃-280℃
Bed temperature 90-100℃
Bed materia glass, PEI, spring steel plate
Bottom printing temperature 260℃-280℃
Sealed printing supports open printing, and the sealing effect is
better if it is sealed
Printing speed 30-150mm/s
Drying conditions 80℃，4H



Part II:Physical Properties of Materials

Property Testing Method Unit  Typical Value
Density(g/cm³ at 21.5 ° C） ASTM D792 (ISO 1183, GB/T 1033) g/cm³ 1.17
Vicat Softening Temperature(° C) ASTM D1525 (ISO 306 GB/T 1633) ℃ /
Heat distortion temperature(° C) ASTM D648 1.8MPa 0.45MPa ℃ 86
Glass transition temperature (° C) DSC, 10 ° C/min ℃ 104
Melt Index(g/10 min) 220 ° C, 10kg 240 ° C, 2.16 kg g/10min 10



Part III:Mechanical Properties of Printed Samples

Property Test conditions Test standards unit  Typical Value
Tensile strength X-Y 50mm/min GB/T 1040.4 MPa 34.2
Elastic modulus X-Y 50mm/min GB/T 1040.1-2006 MPa 1857.9
Elongation at break X-Y 50mm/min GB/T 1040.4 MPa 4.3
Tensile strength X-Z 50mm/min GB/T 1843 MPa 21.2
Elastic modulus X-Z 50mm/min GB/T 1040.1-2006 MPa 1593.1
Elongation at break X-Z 50mm/min GB/T 1040.4 % 2.1
Bending strength 2mm/min GB/T 9341 MPa 54.3
Bending modulus 2mm/min GB/T 9341 MPa 2623.5
Charpy Impact strenght 2.75J GB/T 1043.1-2008 kJ/m2 9.6



Note: All splines are printed under the following conditions: printing temperature=270 ° C, printing
speed=80mm/s, base plate 95 ° C, filling=100%, nozzle diameter=0.4mm
